Table 21 ( Continuation ) : Modbus memory map (Table 2)
Parameter Symbol Tariff 1 Tariff 2 Tariff 3 Total Units
Generation Cost $ 84-85 AE-AF D8-D9 102-103 x10
Hours per tariff Hours 86-87 B0-B1 DA-DB 104-105 sec
4.10.3.3. Voltage and current harmonics.
All the adresses of Modbus memory are in Hexadecimal.
For these variables is implemented the Function 0x03 and 0x04.
Table 22:Modbus memory map (Table 3).
Parameter L1 Voltage L2 Voltage L3 Voltage Units
Fundamental Harm. A28-A29 A48-A49 A68-A69 V x 10
2nd Order harmonic A2A A4A A6A % x 10
3rd Order harmonic A2B A4B A6B % x 10
4th Order harmonic A2C A4C A6C % x 10
5th Order harmonic A2D A4D A6D % x 10
6th Order harmonic A2E A4E A6E % x 10
7th Order harmonic A2F A4F A6F % x 10
8th Order harmonic A30 A50 A70 % x 10
9th Order harmonic A31 A51 A71 % x 10
10th Order harmonic A32 A52 A72 % x 10
11th Order harmonic A33 A53 A73 % x 10
12th Order harmonic A34 A54 A74 % x 10
13th Order harmonic A35 A55 A75 % x 10
14th Order harmonic A36 A56 A76 % x 10
15th Order harmonic A37 A57 A77 % x 10
16th Order harmonic A38 A58 A78 % x 10
17th Order harmonic A39 A59 A79 % x 10
18th Order harmonic A3A A5A A7A % x 10
19th Order harmonic A3B A5B A7B % x 10
20th Order harmonic A3C A5C A7C % x 10
21st Order harmonic A3D A5D A7D % x 10
22nd Order harmonic A3E A5E A7E % x 10
23rd Order harmonic A3F A5F A7F % x 10
24th Order harmonic A40 A60 A80 % x 10
25th Order harmonic A41 A61 A81 % x 10
26th Order harmonic A42 A62 A82 % x 10
27th Order harmonic A43 A63 A83 % x 10
28th Order harmonic A44 A64 A84 % x 10
29th Order harmonic A45 A65 A85 % x 10
30th Order harmonic A46 A66 A86 % x 10
31st Order harmonic A47 A67 A87 % x 10
76
