Table 23:Modbus memory map (Table 4).
Parameter L1 Current L2 Current L3 Current Units
Fundamental Harm. A88-A89 AA8-AA9 AC8-AC9 mA x 10
2nd Order harmonic A8A AAA AAC % x 10
3rd Order harmonic A8B AAB ACB % x 10
4th Order harmonic A8C AAC ADC % x 10
5th Order harmonic A8D AAD ACD % x 10
6th Order harmonic A8E AAE ACE % x 10
7th Order harmonic A8F AAF ACF % x 10
8th Order harmonic A90 AB0 AD0 % x 10
9th Order harmonic A91 AB1 AD1 % x 10
10th Order harmonic A92 AB2 AD2 % x 10
11th Order harmonic A93 AB3 AD3 % x 10
12th Order harmonic A94 AB4 AD4 % x 10
13th Order harmonic A95 AB5 AD5 % x 10
14th Order harmonic A96 AB6 AD6 % x 10
15th Order harmonic A97 AB7 AD7 % x 10
16th Order harmonic A98 AB8 AD8 % x 10
17th Order harmonic A99 AB9 AD9 % x 10
18th Order harmonic A9A ABA ADA % x 10
19th Order harmonic A9B ABB ADB % x 10
20th Order harmonic A9C ABC ADC % x 10
21st Order harmonic A9D ABD ADD % x 10
22nd Order harmonic A9E ABE ADE % x 10
23rd Order harmonic A9F ABF ADF % x 10
24th Order harmonic AA0 AC0 AE0 % x 10
25th Order harmonic AA1 AC1 AE1 % x 10
26th Order harmonic AA2 AC2 AE2 % x 10
27th Order harmonic AA3 AC3 AE3 % x 10
28th Order harmonic AA4 AC4 AE4 % x 10
29th Order harmonic AA5 AC5 AE4 % x 10
30th Order harmonic AA6 AC6 AE6 % x 10
31st Order harmonic AA7 AC7 AE7 % x 10
4.10.3.4. Deleting parameters.
All the Modbus map addresses are hexadecimal.
The 0x05 function is implemented for these variables.
Table 24:Modbus memory map: Deleting parameters.
Parameters
Address Valid data margin
Deleting energies 834 FF00
Deleting maximum and minimum values 838 FF00
Starting maximum demand 839 FF00
Deleting the hour counters (All tariffs) 83D FF00
Deleting the maximum value of the maximum demand 83F FF00
Deleting energies, maximum demand and maximum and
minimum values
848 FF00
77
