4.10.3.5. Power status.
All the Modbus map addresses are hexadecimal.
The 0x04 function is implemented for this variable.
This variable indicates the quadrant in which the device is operating.
Table 25:Modbus memory map: Power status
Power status
Variable Address Default value
Power status 7D1 -
The variable format is shown in Table 26:
Table 26:Variable format: Power status.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 1: Capacitive 1: Inductive 1: Generated 1: Consumed
4.10.3.6. The unit’s serial number.
All the Modbus map addresses are hexadecimal.
The 0x04 function is implemented for this variable.
Table 27:Modbus memory map: Serial number.
The unit’s serial number
Variable Address Default value
Serial number 578 - 579 -
4.10.3.7. Device conguration variables.
All the Modbus map addresses are hexadecimal.
The 0x04 and 0x10 functions are implemented for this variable.
The device’s Modbus function does not check whether the variables recorded are within the
correct margins, they are only checked when they are read from the EEPROM. So if any
parameter is recorded with an incorrect value the device will be congured with its default value.
The Modbus conguration will not take effect until the device is reset.
4.10.3.7.1. Transformation ratios.
Table 28:Modbus memory map: Transformation ratios.
Transformation ratios
Configuration variable
(1) (2)
Address Valid data margin
Default
value
Voltage primary 2710 - 2711 1 - 599999 1
Voltage secondary 2712 1 - 999 1
Current primary 2713 1 - 10000 5
Current secondary 2714
1: .../1A
5: ../5 A
5
(1)
All variables must be programmed at the same time.
(2)
Voltage ratio x Current ratio < 600000.
