Cirrus DESIGN SR22T - Page 253

Cirrus Design Section 7
SR22T Airplane and Systems Description
P/N 13772-003 7-51
Figure 7-11
Circuit Breaker Panel
STALL
VANE HEAT
EVS
CAMERA
CABIN AIR
CONTROL
CABIN
FAN
STARTER
AVIONICS
FAN 1
RECOG
LIGHTS
NAV
LIGHTS
STROBE
LIGHTS
PITOT
HEAT
FLAPS
AVIONICS
FAN 2
GPS NAV
GIA 2
COM 2
AHRS 2
FUEL
PUMP
PFD #2
MFD #1
12V DC
OUTLET
YAW
SERVO
ALT1
A/C COND
A/C COMPR
SR22_FM03A_2949A
BAT 2
GPS NAV
GIA 1
COM 1
ADC 1
STDBY
ATTD #1
PFD #1
PITCH
TRIM
ROLL
TRIM
ENGINE
INSTR
ALT2
STALL
WARNING
ESSENTIAL
POWER
AHRS 1
DME / ADF
AUDIO
PANEL
WEATHER
TRAFFIC
AP SERVOS
FUEL QTY
MFD #2
STDBY
ATTD #2
CABIN LIGHTS
/ OXYGEN
KEYPADS
/ AP CTRL
XPONDER
ICE
PROTECTION
AVIONICS
Original Issue
