Cisco 7925G Deployment Guide

Cisco Unified Wireless IP Phone 7925G, 7925G-EX, and 7926G Deployment Guide
19
• Ring
• Answer a call
• End a call
• Volume Control
Hands-Free Profile (HFP)
With Bluetooth Hands-Free Profile (HFP) support, the following additional features can be available if supported by the
Bluetooth headset.
• Last Number Redial
• Call Waiting
• Divert / Reject
• 3 way calling (Hold & Accept and Release & Accept)
• Speed Dialing
For more information, refer to the documentation from the Bluetooth headset manufacturer.
Coexistence (802.11b/g + Bluetooth)
If using Coexistence where 802.11b/g and Bluetooth are used simultaneously, then there are some limitations and deployment
requirements to be considered as they both utilize the 2.4 GHz frequency range.
Capacity
When using Coexistence (802.11b/g + Bluetooth), call capacity is reduced due to the utilization of CTS to protect the 802.11g
and Bluetooth transmissions.
Multicast Audio
Multicast audio from Push To Talk (PTT), Music on Hold (MMOH) and other applications are not supported when using
Coexistence.
Voice Quality
Depending on the current data rate configuration, CTS may be sent to protect the Bluetooth transmissions when using
Coexistence.
In some environments, 6 Mbps may need to be enabled.
Note: It is highly recommended to use 802.11a if using Bluetooth due to 802.11b/g and Bluetooth both utilizing 2.4 GHz, but
also due to the above limitations.
Security
When deploying a wireless LAN, security is essential.
The Cisco Unified Wireless IP Phone 7925G, 7925G-EX, and 7926G support the following wireless security features.
WLAN Authentication
• WPA (802.1x authentication + TKIP or AES encryption)

Cisco 7925G Specifications

General

Keypad number of keys	12
Display diagonal	2 \
Display resolution	176 x 220 pixels
Call waiting	Yes
Lines quantity	6 lines
Voice codecs	G.711a, G.722, G.729a, iLBC
Security algorithms	128-bit WEP, SSL/TLS, WPA
Supported network protocols	DHCP, TFTP, DNS, SCCP, SRST
Input voltage	100 - 240 V
Dimensions (WxDxH)	52 x 20 x 127 mm
Minimum system requirements	Cisco Unified Communications Manager 4.1, 4.2, 4.3, 5.1, 6.0, 6.1, 7.0 + Cisco Unified Communications Manager Express 4.3 +
Input frequency	50/60 Hz
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Product type	IP Phone
Product color	Gray
Safety	UL 60950, CSA 22.2 No.60950, EN 60950, IEC 60950, AS/NZS 60950, IEC 60529 (IP 54)
Certification	47 CFR 15 B ICES-003 B EN 55022 B AS/NZS CISPR 22 B CISPR 22 B VCCI B EN 61000-3-2 EN 61000-3-3 KN 22 EN 55024 EN 50082-1 EN 61000-6-1 EN 300386 EN 60601-1-2 KN
Compliance industry standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.1X, IEEE 802.11e

Weight and Dimensions

Weight	138 g
