10-11
Cisco Catalyst Blade Switch 3120 for HP Software Configuration Guide
OL-12247-01
Chapter 10 Configuring Interface Characteristics
Using Interface Configuration Mode
Use the no define interface-range macro_name global configuration command to delete a macro.
When using the define interface-range global configuration command, note these guidelines:
• Valid entries for interface-range:
– vlan vlan-ID - vlan-ID, where the VLAN ID is 1 to 4094
– gigabitethernet stack member/module/{first port} - {last port}, where the module is always 0
– tengigabitethernet stack member/module/{first port} - {last port}, where the module is
always 0
– port-channel port-channel-number - port-channel-number, where the port-channel-number
is 1 to 48.
Note When you use the interface ranges with port channels, the first and last port-channel
number must be active port channels.
• You must add a space between the first interface number and the hyphen when entering an
interface-range. For example, gigabitethernet1/0/1 - 4 is a valid range; gigabitethernet1/0/1-4 is
not a valid range.
• The VLAN interfaces must have been configured with the interface vlan command. The show
running-config privileged EXEC command displays the configured VLAN interfaces. VLAN
interfaces not displayed by the show running-config command cannot be used as interface-ranges.
• All interfaces defined as in a range must be the same type (all Gigabit Ethernet ports, all 10-Gigabit
Ethernet ports, all EtherChannel ports, or all VLANs), but you can combine multiple interface types
in a macro.
This example shows how to define an interface-range named enet_list to include ports 1 and 2 on
switch 1 and to verify the macro configuration:
Switch# configure terminal
Switch(config)# define interface-range enet_list gigabitethernet1/0/1 - 2
Switch(config)# end
Switch# show running-config | include define
define interface-range enet_list GigabitEthernet1/0/1 - 2
This example shows how to create a multiple-interface macro named macro1:
Switch# configure terminal
Switch(config)# define interface-range macro1 gigabitethernet1/0/1 - 2,
gigabitethernet1/0/5 - 7, tengigabitethernet1/0/1 -2
Switch(config)# end
This example shows how to enter interface-range configuration mode for the interface-range
macro enet_list:
Switch# configure terminal
Switch(config)# interface range macro enet_list
Switch(config-if-range)#
Step 5
show running-config | include define Show the defined interface range macro configuration.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
