36-17
Cisco Catalyst Blade Switch 3120 for HP Software Configuration Guide
OL-12247-01
Chapter 36 Configuring QoS
Understanding QoS
Queueing and Scheduling on Egress Queues
Figure 36-9 shows the queueing and scheduling flowchart for egress ports.
Note If the expedite queue is enabled, SRR services it until it is empty before servicing the other three queues.
Figure 36-9 Queueing and Scheduling Flowchart for Egress Ports
Each port supports four egress queues, one of which (queue 1) can be the egress expedite queue. These
queues are configured by a queue-set. All traffic leaving an egress port flows through one of these four
queues and is subjected to a threshold based on the QoS label assigned to the packet.
86694
Receive packet from
the stack ring.
Read QoS label
(DSCP or CoS value).
Determine egress queue
number and threshold
based on the label.
Are thresholds
being exceeded?
Send the packet
out the port.
Queue the packet. Service
the queue according to
the SRR weights.
Drop packet.
Start
Done
Ye s
No
Rewrite DSCP and/or
CoS value as
appropriate.

Cisco Catalyst 3120 Specifications

General

Ports	24 x 10/100 + 2 x SFP
MAC Address Table Size	8K entries
Power Supply	AC 120/230 V (50/60 Hz)
Device Type	Switch
Form Factor	Rack-mountable
Routing Protocol	RIP-1, RIP-2, static IP routing
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, CLI
Features	DHCP support, VLAN support, auto-negotiation, IPv6 support, Access Control List (ACL) support, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, IGMP snooping
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Dimensions (H x W x D)	1.7 in x 17.5 in
Operating Temperature	32 °F
Operating Humidity	10%
