38-6
Cisco Catalyst Blade Switch 3120 for HP Software Configuration Guide
OL-12247-01
Chapter 38 Configuring IP Unicast Routing
Configuring IP Addressing
• Configuring Address Resolution Methods, page 38-9
• Routing Assistance When IP Routing is Disabled, page 38-12
• Configuring Broadcast Packet Handling, page 38-14
• Monitoring and Maintaining IP Addressing, page 38-18
Default Addressing Configuration
Table 38-1 shows the default addressing configuration.
Table 38-1 Default Addressing Configuration
Feature Default Setting
IP address None defined.
ARP No permanent entries in the Address Resolution Protocol (ARP) cache.
Encapsulation: Standard Ethernet-style ARP.
Timeout: 14400 seconds (4 hours).
IP broadcast address 255.255.255.255 (all ones).
IP classless routing Enabled.
IP default gateway Disabled.
IP directed broadcast Disabled (all IP directed broadcasts are dropped).
IP domain Domain list: No domain names defined.
Domain lookup: Enabled.
Domain name: Enabled.
IP forward-protocol If a helper address is defined or User Datagram Protocol (UDP) flooding is
configured, UDP forwarding is enabled on default ports.
Any-local-broadcast: Disabled.
Spanning Tree Protocol (STP): Disabled.
Turbo-flood: Disabled.
IP helper address Disabled.
IP host Disabled.
IRDP Disabled.
Defaults when enabled:
• Broadcast IRDP advertisements.
• Maximum interval between advertisements: 600 seconds.
• Minimum interval between advertisements: 0.75 times max interval
• Preference: 0.
IP proxy ARP Enabled.
IP routing Disabled.
IP subnet-zero Disabled.
