Page #167 background image
CHAPTER 8
Powering Up the Cisco cBR Chassis
Powering Up the Cisco cBR, on page 159
Powering Up the Cisco cBR
Before you begin
After all the interfaces and other cables are connected, perform a visual check of all connections and check
that:
The ejector levers on each line card are in the locked position.
All the top and bottom line card captive screws are tight.
All network interface cables are connected.
The console terminal is turned on.
Step 1 Make sure the chassis ground connection is attached.
Step 2 Push the toggle switch on the FPEM (AC or DC) on the rear of the chassis to ON position.
What to do next
Ensure the POWER ENABLE LED on the FPEM illuminates green.
Verify if the LEDs on the Power Modules indicate input voltage presence within correct range.
Cisco Converged Broadband Routers Hardware Installation Guide
159
