Cisco cBR Series Hardware Installation Guide

CHAPTER 11
Monitoring the Power System in the Cisco cBR
Chassis
• Monitoring the Power System in the Cisco cBR Chassis Using LEDs, on page 171
• Monitoring the Power System in the Cisco cBR Chassis Using CLI, on page 173
Monitoring the Power System in the Cisco cBR Chassis Using
LEDs
Table 33: Verifying the LEDs on the AC FPEM
DescriptionStatusLED
The chassis power is on.GreenPOWER ENABLE
LED
The chassis power is off.Off
VER 01 of the AC FPEM has P0 AC PRESENT LED through P5 AC PRESENT LED. The PRESENT LEDs
indicate input AC power for the corresponding AC Power Modules (also indicated on the front of the Power
Module). Updated AC FPEM started shipping from April, 2018.
Note
Table 34: Verifying the LEDs on the DC FPEM
DescriptionStatusLED
The chassis power is on.GreenPOWER ENABLE
LED
The chassis power is off.Off
