Figure 28: Attaching the Chassis Installation Handles to the Cisco CBR-8 Router

Chassis3Chassis Installation Handle1

—Captive Screw2

The rack mount brackets support both low and high installation of the handles. It facilitates low or high chassis installation

in the rack.

What to do next

Install the Cisco cBR-8 router in the rack.

Installing the Cisco cBR-8 in a Rack

You can install the chassis in either a four-post rack unit or a two-post rack unit.

Before you begin

1. Verify rack dimensions.

2. Install chassis installation brackets.

3. Attach the chassis rack-mount brackets.

Cisco Converged Broadband Routers Hardware Installation Guide

Installing the Cisco cBR Chassis

Installing the Cisco cBR-8 in a Rack

Default Chapter4
