Installing the Fan Module in Cisco cBR
• Installing the Fan Module in the cBR Chassis, on page 73
Installing the Fan Module in the cBR Chassis
Before you begin
• Attach an ESD-preventive wrist strap to your wrist and connect the other end to the grounding lug
connected to the chassis.
• Minimum Keep Out Areas for Proper Cooling
Air flows from the front to the rear of the chassis. Air enters through the chassis front panel. Additionally,
a small air inlet area is on the front right side in front of the mounting ear. Air is expelled from the rear
of the chassis and a small exhaust area on the rear left side.
The keep-out areas are defined to ensure adequate space around the Cisco cBR-8 chassis. The space is
necessary to ensure adequate air intake and exhaust. The figure shows the keep-out areas for the Cisco
cBR-8 chassis.
Cisco Converged Broadband Routers Hardware Installation Guide
73

Cisco cBR Series Specifications

General

Category	Network Router
Modular Design	Yes
Operating System	Cisco IOS XE
Model Examples	cBR-8, cBR-4
Product Series	cBR Series
Purpose	Converged Broadband Router
DOCSIS Support	DOCSIS 3.1
Redundancy	Yes
Management	Cisco Prime
Product Family	cBR Series
Downstream Frequency Range	Up to 1.2 GHz
Upstream Frequency Range	Up to 204 MHz
Modulation Schemes	QAM
Power Supply	Redundant AC or DC power supplies
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5 to 95% noncondensing
