Figure 13: Supervisor PIC
Timing port (1 PPS)8Ejector lever1
Timing port (10 MHz)9QSFP ports2
Console port10Auxiliary port3
LEDs11DTI ports4
Captive screws12NME ports5
10G LED13CM/DTP port6
TOD port7
Table 15: Physical Specifications of the Supervisor PIC
ValueUnit
8.1 in (20.6 cm)Depth
11.79 in (29.9 cm)Width
2.82 in (7.16 cm)Height
3.44 lb (1.56 kg)Maximum weight
