4035197 Rev C D9865 Satellite Receiver Installation and Operation Guide 4-57
Setting the Unicast IP Address, Continued
2. The following table describes each of the options:
The Network Address, Mask, and Gateway Address should be changed together, as
a group. The following table shows the most commonly used Subnet mask values to
enter for a chosen IP address mask, which will depend on the size of your network.
3. Select the green button (Save).
Editing a Unicast IP Address
1. In the Unicast IP Setup screen, scroll to the unicast IP you want to edit using the
 buttons.
2. Press OK. The Edit/Delete Unicast IP screen is displayed.
3. Select Edit or press the blue button (Edit). The Add/Edit Unicast IP screen is
displayed.
4. Make the necessary changes.
5. Select the green button (Save).
Deleting a Unicast IP Address
1. In the Unicast IP Setup screen, scroll to the unicast IP you want to delete using
the
 buttons.
2. Press OK. The Edit/Delete Unicast IP screen is displayed.
3. Select Delete or press the red button (Delete). A message appears to confirm the
deletion.
4. Press OK.
Selection Options Description
Network Address 12 digits in length
(###.###.###.###)
Sets the IP Address for its participation
in a Network environment
Mask 8 to 32 Sets Subnet Mask for its participation in
a Network environment.
Gateway Address 12 digits in length
(###.###.###.###)
Sets the Network Gateway Address on
the Network, used to expose the
receiver to a WAN.
Mask Subnet Mask
8 255.0.0.0
16 255.255.0.0
24 255.255.255.0
