Cisco TelePresence Multipoint Switch Release 1.1 Administration Guide
OL-12586-02
Chapter 4 Configuring CTMS Administration Software
System Settings
• To register new or modified settings, click Apply.
• To restore the original settings, click Reset.
Note We recommend that you use the same Quality settings for CTSM that you have configured in Cisco
Unified Communications Manager for Cisco TelePresence Systems endpoints.
DSCP for Signaling Traffic queuing techniques that define per-hop behavior based on the
Differentiated Services Code Point (DSCP) value in the IP header of
a packet. control stream
Available settings are:
• AF11 DSCP (001010)
• AF12 DSCP (001100)
• AF13 DSCP (001110)
• AF21 DSCP (010010)
• AF22 DSCP (010100)
• AF23 DSCP (010110)
• AF31 DSCP (011010)
• AF32 DSCP (011100)
• AF33 DSCP (011110)
• AF41 DSCP (100010)
• AF42 DSCP (100100)
• AF43 DSCP (100110)
• CS1 (precedence 1) DSCP (001000)
• CS2 (precedence 2) DSCP (010000)
• CS3 (precedence 3) DSCP (011000)
• CS4 (precedence 4) DSCP (100000)
• CS5 (precedence 5) DSCP (101000)
• CS6 (precedence 6) DSCP (110000)
• CS7 (precedence 7) DSCP (111000)
• Default DSCP (000000)
• EF DSCP (101110)
The default value for this field is CS3 (precedence 3) (011000). It is
recommended that you use the default value for this field.
Table 4-3 QoS Settings
