4-28
Cisco TelePresence Multipoint Switch Release 1.1 Administration Guide
OL-12586-02
Chapter 4 Configuring CTMS Administration Software
System Settings
Configuring and Editing Resource Management
Figure 4-4 shows the Resource Management Settings screen.
Figure 4-4 Resource Management Settings
To configure or edit Resource Management settings:
Step 1 Click System Settings under the System Configuration folder in the Navigation Pane.
Step 2 Click the Resource Management tab. Resource Management displays a table providing the Resource
Management Settings configuration fields.
Enter or edit settings (as needed) as described in Tabl e 4 -4
Table 4-4 Resource Management Settings
Field or Button Setting
Maximum Segments Defines the total number of table segments (individual video
displays) this CTMS handles. Maximum number is 48.
