8-80
Cisco TelePresence Multipoint Switch Release 1.1 Administration Guide
OL-12586-02
Chapter 8 Interoperability with Legacy Video Conferencing Devices
Configuring Cisco TelePresence Interoperability
Creating a SIP Trunk
To create a SIP trunk for CTMS calls to the CUVC:
Step 1 Click Device. Click Trunk.
Step 2 Click the Add New button at the bottom or click the + sign at the top of the Trunk Configuration page.
Step 3 Select SIP Trunk from the Trunk Type pull-down menu, then click Next.
Step 4 Enter the settings as indicated in Table 8-2 to configure the SIP trunk. Leave default settings for fields
not included in Table 8-2.
.
Step 5 Click the Save button at the bottom of the page.
Configuring a Route Pattern
A route pattern allows a Unified CM-managed device to access another device by dialing its number.
Such devices may include gateways, Cisco TelePresence Multipoint Switch (CTMS) systems, or Cisco
Unified Video Conferencing (CUVC) units. Each device requires its own unique route pattern.
To configure a route pattern:
Step 1 Click Call Routing. Under Route/Hunt, click Route Pattern.
Step 2 Click the Add New button at the bottom or click the + sign at the top of the Route Pattern Configuration
page.
Table 8-2 SIP Trunk Settings
Field Required Setting
Device Information
Device Name Yes Enter a text string identifying this SIP trunk.
Description — Enter a text string describing this SIP trunk.
Device Pool Yes Select Default.
SIP Information
Destination Address Yes Enter the IP address of the CUVC.
SIP Trunk Security Profile Yes Select the SIP trunk security profile that you
created for CTMS.
SIP Profile Yes Select Standard SIP Profile.
To Next Page
