7-70
Cisco TelePresence Multipoint Switch Release 1.1 Administration Guide
OL-12586-02
Chapter 7 Monitoring CTMS System Processes
Viewing Call Statistics
Viewing Call Statistics
Use Call Statistics to view detailed RTP information about all call segments for active CTMS meetings.
To view call statistics:
Step 1 Click Call Status under the Monitoring folder in the Navigation Pane to open the Call Statistics
window. Figure 7-4 shows the Call Statistics screen.
Figure 7-4 Call Statistics Screen
Step 2 The initial Call Statistics screen displays a table providing the following information, listing all currently
active meetings by ID numbers:
Step 3 To use the filter at the top of the table to find a particular meeting, enter either the Meeting ID number
or the Room number in the appropriate field and then press “Filter.”
Table 7-2 Call Statistics Table Field Descriptions
Field Description
Meeting ID ID number uniquely identifying an active meeting.
Description Text describing the active meeting.
Type Displays the defined meeting type. Meeting types are static and
ad hoc.
Rooms Lists the CTS end points (meeting rooms) attending this meeting.
Duration Length of time this meeting has been active, listed in hours, minutes
and seconds.
Segments Total number of segments for all rooms attending this meeting.
