4-33
Cisco TelePresence Multipoint Switch Release 1.1 Administration Guide
OL-12586-02
Chapter 4 Configuring CTMS Administration Software
Cisco Unified Communications Manager Settings
Configuring and Editing Unified CM Settings
Figure 4-8 shows the Unified CM Settings screen.
Figure 4-8 Unified CM Settings
To configure or edit Unified CM settings:
Step 1 Click Unified CM Settings under the System Configuration folder in the Navigation Pane.
Step 2 Click the Unified CM Settings tab. Unified CM Settings displays a table providing the Unified CM
Settings configuration fields. Enter settings (as needed) as described in Table 4-6
• To register new or modified settings, click Apply.
• To restore the original settings, click Reset.
Configuring and Editing SIP Profile Settings
Figure 4-9 shows the SIP Profile Settings screen.
Table 4-6 Unified CM Settings
Field or Button Setting
Unified CM 1 through 5 Hostnames or IP address(es) of the Cisco Unified Communications
Manager (Unified CM) server.
Note It is important to add all Unified CM servers in the cluster.
SIP Port Port number for Cisco Unified SIP IP Phones that are using UDP to listen
for SIP messages from Unified CM. The default setting equals 5060.
