13
Data - Summary Screen
System Information
Firmware Ver-
sion
It displays the current firmware version installed on this Router.
CPU
Displayed here are the type and speed of the processor installed on the
Router.
System Up Time
This is the length of time in days, hours, and minutes that the Router
has been active. The current time and date are also displayed.
DRAM
Displayed here is the size of DRAM installed on the Router’s mother-
board.
FLASH
Displayed here is the size of flash memory installed on the Router’s
board.
Port Statistics
Port Statistics This section displays the following color-coded status information on
the Router’s Ethernet ports:
• Green - Indicates that the port has a connection.
• Black - Indicates that the port has no connection.
Networking Setting Status
LAN IP
Displays the IP address of the Router’s LAN interface.
WAN IP
Displays the IP address of the Router’s WAN interface. If this address
was assigned using DHCP, click DHCP Release to release the address,
or click DHCP Renew to renew the address.
Mode
Displays the operating mode, Gateway or Router.
Gateway
Displays the Gateway address, which is the IP address of your ISP’s
server.
DNS 1-2
The IP addresses of the Domain Name System (DNS) server(s) that the
Router is using.
DDNS
Indicates whether the Dynamic Domain Name System (DDNS) feature
is enabled.
DMZ
Indicates whether the DMZ Hosting feature is enabled.
Firewall Setting Status
DOS (Denial of
Service)
Indicates whether the DoS Protection feature is enabled to block DoS
attacks.
Block WAN
Request
Indicates whether the Block WAN Request feature is enabled.
Remote Man-
agement
Indicates whether the Remote Management feature is enabled.
VPN Setting Status
Tunnel(s) Used
Displays the number of VPN tunnels currently being used.
Tunnel(s) Avail-
able
Displays the number of VPN tunnels that are available.
