74
QoS Tab
QoS (Quality of Service) allows you to perform Bandwidth Management, by either Rate
Control or Priority. You can also configure QoS Trust Mode and the DSCP settings.
QoS - Bandwidth Management
Figure 43: Bandwidth Management Screen
Setup
Bandwidth
Management
QoS (Quality of Service) is disabled by default. When enabled, this
option allows you to assign priority based on the application type.
Bandwidth
This section lets you specify the maximum bandwidth provided by the
ISP on the WAN interface, for both the upstream and downstream
directions.
Bandwidth Management Type
Type
The desired type of bandwidth management, either Rate Control or
Priority. Depending on your selection, the lower portion of the screen
displays either the Rate Control section or the Priority section.
Rate Control
Service
Select the service from the drop-down menu. If it does not contain the
service you need, click Service Management to add the service.
IP
Enter the IP address or IP range you need to control. The default is
zero, which includes all internal IP addresses.
Direction
Select Upstream for outbound traffic or Downstream for inbound
traffic.
To Next Page
