66
VPN - IPSec VPN Tab
Use this screen to create VPN tunnels between the Router to the remote Router. All Linksys
Routers with Ipsec VPN support can be used as a remote Router (e.g. RVS4000, WRV54G,
RV042). The Router supports VPN tunnels using IPsec (IP Security) technologies. You can
create, delete, or modify a VPN tunnel on this page.
Figure 40: IPSec VPN Screen
IPSec VPN
Tunnel Selected
Select a tunnel to configure or create a new tunnel.
Delete Button
Click this button to delete the selected tunnel.
Tunnel Name
For each application, list the forwarded port number range. These are
the ports used by incoming traffic. Check with the Internet application
documentation for the port number(s) needed. In the first field, enter
the starting port number of the Forwarded Range. In the second field,
enter the ending port number of the Forwarded Range.
