77
QoS - Queue Settings
Figure 46: Queue Settings
QoS Setup Queue Settings
Queue
The number of the Queue.
Strict Priority
Select either
Strict Priority
or
WRR
. The default is
Strict Priority
.
WRR
If WRR enabled, enter the values for
WRR Weight
and
% of WRR
Bandwidth
.
78
