91
L2 Switch - Radius
Figure 57: Radius Screen
Radius
Mode
Select Enabled or Disabled from the drop-down menu to enable or
disable RADIUS.
Radius IP
Enter the Server IP address.
Radius UDP Port
Enter the UDP port. The UDP port is used to verify the RADIUS
server authentication.
Radius Secret
Enter the Key string used for authenticating and encrypting all
RADIUS communications between the device and the RADIUS
server. This key must match the RADIUS server encryption key. If
no host-specific value is specified, the global value applies to each
host.
Administration
State
Specifies the port authorization state. The possible field values are:
• Auto - The controlled port state is set by the Authentication
method.
• Force Authorized - The controlled port state is set to Force-
Authorized (forward traffic).
• Force Unauthorized - The controlled port state is set to Force-
Unauthorized (discard traffic).
Port State
Displays the state of the selected port.
