48
Enable
This tells the Router if the rule is active or not. You can have rules
defined in the ACL Table but in an inactive state. The administrator
can decide on when to enable specific ACL rules manually.
Action
This defines how the rule is to affect the traffic. It can be either Allow
or Deny. If the rule is matched and the action is Allow, the packet will
be forwarded. If the rule is matched and the action is Deny, the packet
will be dropped.
Service
You can either select one of the pre-defined services in the drop-down
menu or you can define new services by clicking the Service Manage-
ment button. Once you defined your own service, it will be listed on
the top of the drop-down menu. You can also select ALL to allow or
block all types of IP traffic.
The User-defined Service GUI page can be either accessed from the
New Rule screen by clicking Service Management button, or you can
access it directly from the 2nd layer tab under Firewall.
Source Interface
Select LAN, WAN, or ANY interface.
Source
This is the source IP address to be matched against. You can define a
Single IP address, a Range of IP addresses (start IP and end IP), a
Network (IP Prefix and Network Mask), or ANY IP addresses.
Destination
This is the destination IP address to be matched against. You can
define a Single IP address, a Range of IP addresses (start IP and end
IP), a Network (IP Prefix and Network Mask), or ANY IP addresses.
Time
Displays the time period this rule will be enabled (used together with
Date). It can be set to Any Time.
Day
Displays the days in a week this rule will be enabled (used together
with Time). It can be set to Any Day.
Edit Button
Use this button to go to Edit IP ACL Rule screen and modify this rule.
Delete Button
Use this button to delete the ACL rule from the list.
Add New Rule
Click this button to enter the page to define a new ACL rule.
Disable All Rule
Click this page to disable all the user-defined rules.
Delete All Rules
Click this page to delete all the user-defined rules.
Edit IP ACL Rule
This Web page can be entered only through IP Based ACL Tab. You can enter this page by
clicking Add New Rule button on that page.
