Client Quality of Service
Policy Map
Cisco WAP571/E Administration Guide 130
8
- Committed Rate—The committed rate, in Kbps, to which traffic must
conform. The range is from 1 to 1000000 Kbps.
- Committed Burst—The committed burst size, in bytes, to which traffic
must conform. The range is from 1 to 204800000 bytes.
• Send—Specifies that all packets for the associated traffic stream are to be
forwarded if the class map criteria is met.
• Drop—Specifies that all packets for the associated traffic stream are to be
dropped if the class map criteria is met.
• Mark Class of Service—Marks all packets for the associated traffic stream
with the specified class of service value in the priority field of the 802.1p
header. If the packet does not already contain this header, one is inserted.
The CoS value is an integer from 0 to 7.
• Mark IP DSCP—Marks all packets for the associated traffic stream with the
IP DSCP value that you select from the list.
- Select From List—A list of DSCP types.
• Mark IP Precedence—Marks all packets for the associated traffic stream
with the specified IP precedence value. The IP precedence value is an
integer from 0 to 7.
• Disassociate Class Map—Removes the class selected in the Class Map
Name list from the policy selected in the Policy Map Name list.
• Member Classes—Lists all DiffServ classes currently defined as members
of the selected policy. If no class is associated with the policy, the field is
empty.
STEP 5 Click Save. The changes are saved to the Startup Configuration.
NOTE To delete a policy map, select it in the Policy Map Name list and click Delete.
NOTE A policy map can only be deleted when it is not associated to any VAP.
NOTE The policy marking parameters such as Mark Class of Service, Mark IP DSCP and
Mark IP Precedence are not supported for IPV6 Class Map.
