Captive Portal
Web Portal Customization
Cisco WAP571/E Administration Guide 166
11
NOTE Clicking Preview will show the text and images that have already been saved to the
Startup Configuration. If you make a change, click Save before clicking Preview to
see your changes.
Uploading and Deleting Images
When users initiate access to a VAP that is associated with a CP instance, an
authentication page appears. You can customize the authentication page with your
own logo or other images.
Up to 18 images can be uploaded (assuming six locales, with each locale having
three images). All images must be 5 kilobytes or smaller and must be in GIF or JPG
format.
Images are resized to fit the specified dimensions. For best results, your logo and
account images should be similar in proportion to the default images, as follows:
To upload binary graphic files to the WAP device:
STEP 1 On the Web Portal Customization page, click Upload/Delete Custom Image next
to the Background Image Name, Logo Image Name, or Account Image fields.
The Web Portal Custom Image page appears.
STEP 2 Click Browse to choose the image.
STEP 3 Click Upload.
STEP 4 Click Back to return to the Web Portal Custom Image page.
STEP 5 Choose the Captive Portal Web Locale that you want to configure.
Image Type Use Default Width by
Height
Background Shows as the page background. 10 by 800 pixels
Logo Shows at top left of page to provide
branding information.
168 by 78 pixels
Account Shows above the login field to depict
an authenticated login.
295 by 55 pixels
