ACL
ACL Association
Cisco WAP571/E Administration Guide 142
9
• Source MAC—Requires the packet's source MAC address to match the
address defined in the appropriate fields.
- Source MAC Address—Enter the source MAC address to compare
against an Ethernet frame.
- Source MAC Mask—Enter the source MAC address mask specifying
which bits in the source MAC to compare against an Ethernet frame.
For each bit position in the MAC mask, a 0 indicates that the
corresponding address bit is significant and a 1 indicates that the
address bit is ignored. For example, to check only the first four octets of
a MAC address, a MAC mask of 00:00:00:00:ff:ff is used. A MAC mask of
00:00:00:00:00:00 checks all address bits and is used to match a single
MAC address.
• Destination MAC—Requires the packet's destination MAC address to
match the address defined in the appropriate fields.
- Destination MAC Address—Enter the destination MAC address to
compare against an Ethernet frame.
- Destination MAC Mask—Enter the destination MAC address mask to
specify which bits in the destination MAC to compare against an Ethernet
frame.
• VLAN ID—Enter the specific VLAN ID to compare against an Ethernet
frame.
This field is located in the first/only 802.1Q VLAN tag.
STEP 6 Click Save. The changes are saved to the Startup Configuration.
NOTE To delete an ACL, ensure that it is selected in the ACL Name-ACL Type list, check
Delete ACL, and click Save.
ACL Association
The ACL Association page provides the ACL list bound to the wireless and
Ethernet interfaces. To control general categories of traffic, such as HTTP traffic or
traffic from a specific subnet, you can configure ACLs and assign them to one or
more interfaces.
