LAN
VLAN Configuration
Cisco WAP571/E Administration Guide 64
4
• Duplex Mode—In review mode, it shows the current port duplex mode. In
edit mode, if Auto Negotiation is disabled, select either Half-Duplex or Full-
Duplex.
Auto Negotiation—When enabled, the port negotiates with its link partner to set
the fastest link speed and duplex mode available. When disabled, you can
manually configure the Port Speed and Duplex Mode.
Green Ethernet—Green Ethernet Mode supports both auto-power-down mode
and EEE (Energy Efficient Ethernet, IEEE 802.3az) mode. Green Ethernet Mode
works only when the port has auto-negotiation enabled. Auto-power-down mode
reduces chip power when the signal from a link partner is not present. The WAP
device automatically enters a low-power mode when energy on the line is lost,
and it resumes normal operation when energy is detected. EEE mode supports
QUIET times during low link utilization, allowing both side of a link to disable
portions of each PHY's operating circuit and save power.
• Green Ethernet Status—Shows the current EEE status.
STEP 2 Check the interfaces that you want to edit, then click the Edit button to enter the
edit mode. Then input your settings.
STEP 3 Click Save. The changes are saved to the Startup Configuration.
NOTE The WAP571/E always bundled the two Eth0 and Eth1 to be link aggregation mode.
The link partner must also support link aggregation. Eth1 will always follows Eth0
configurations.
VLAN Configuration
Use the VLAN Configuration page to view and configure the VLAN settings.
To configure the settings for a VLAN:
STEP 1 Select LAN > VLAN Configuration.
STEP 2 In the VLAN Setting Table, each VLAN record includes the following fields:
• VLAN ID—Identifier of the VLAN. Each VLAN ID is ranged from 1 to 4094 and
should be different with others VLAN ID.
