Single Point Setup
Access Points
Cisco WAP571/E Administration Guide 174
12
Access Points
The Access Points page allows you to enable or disable Single Point Setup on a
WAP device, view the cluster members, and configure the location and cluster
name for a member. You can also click the IP address of a member to configure
and view data on that device.
To configure the location and name of an individual Single Point Setup cluster
member:
STEP 1 Select Single Point Setup > Access Points in the navigation pane.
Single Point Setup is disabled by default on the AP. When disabled, the Enable
Single Point Setup button is visible. If Single Point Setup is enabled, the Disable
Single Point Setup button is visible. You can edit Single Point Setup options only
when Single Point Setup is disabled.
Icons on the right side of the page indicate whether Single Point Setup is enabled
and, if it is, the number of WAP devices that are currently joined in the cluster.
STEP 2 With Single Point Setup disabled, configure the following information for each
individual member of a Single Point Setup cluster.
• Location—Enter a description of where the access point is physically
located, for example, Reception. The location field is optional.
• Cluster Name—Enter the name of the cluster for the WAP device to join, for
example Reception_Cluster.
Other Configuration Settings and Parameters That Are Not Propagated in
Single Point Setup
Bandwidth Utilization Port Settings
Bonjour VLAN and IPv4
IPv6 Address WDS Bridge
IPv6 Tunnel
Packet Capture WorkGroup Bridge
