Cisco WAP100 Series Administration Guide

SNMP
Ta r g e t s
Cisco WAP571/E Administration Guide 153
10
Targets
SNMPv3 targets send SNMP notifications using Inform messages to the SNMP
Manager. For SNMPv3 targets, only Informs are sent, not traps. For SNMP versions
1 and 2, traps are sent. Each target is defined with a target IP address, UDP port,
and SNMPv3 user name.
NOTE SNMPv3 user configuration (see the Users page) should be completed before
configuring SNMPv3 targets.
NOTE The AP supports a maximum of eight targets.
To a d d S N M P t a r g e t s :
STEP 1 Select SNMP > Targets in the navigation pane.
STEP 2 Click Add. A new row is created in the table.
STEP 3 Check the box in the new row and click Edit.
STEP 4 Configure the parameters:
• IP Address—Enter the IPv4 address of the remote SNMP manager to
receive the target.
• UDP Port—Enter the UDP port to use for sending SNMPv3 targets.
• Users—Enter the name of the SNMP user to associate with the target. To
configure SNMP users, see the Users page.
STEP 5 Click Save. The user is added to the SNMPv3 Targets list and your changes are
saved to the Startup Configuration.
NOTE To remove an SNMP target, select the user in the list and click Delete.
