Client Quality of Service
Policy Map
Cisco WAP571/E Administration Guide 129
8
• VLAN ID—Specified the VLAN ID to be matched for the packets. The VLAN
ID range is from 0 to 4095.
STEP 5 Click Save. The changes are saved to the Startup Configuration.
NOTE To delete a class map, choose it in the Class Map Name list and click Delete. The
class map cannot be deleted if it is already attached to a policy.
Policy Map
Packets are classified and processed based on defined criteria. The classification
criteria is defined by a class on the Class Map page. The processing is defined by
a policy's attributes on the Policy Map page. Policy attributes may be defined on a
per-class instance basis and determine how traffic that matches the class criteria
is handled.
The WAP device supports up to 50 policy maps. A policy map can contain up to
10 class maps.
To add and configure a policy map:
STEP 1 Select Client QoS > Policy Map.
STEP 2 In the Policy Map Name field, enter the name for the policy map. The name can
include from 1 to 31 alphanumeric characters and special characters. Spaces are
not allowed.
STEP 3 Click Add Policy Map.
STEP 4 In the Policy Class Definition area, configure these parameters for the policy map:
• Policy Map Name—Choose the policy map to configure.
• Class Map Name—Choose the class map to apply this policy.
• Police Simple—Establishes the traffic policing style for the class. The
simple form of the policing style uses a single data rate and burst size,
resulting in two outcomes: conform and nonconform.
If you enable this feature, configure one of these fields:
