Wireless
Networks
Cisco WAP571/E Administration Guide 85
5
ASCII 0x20 through 0x7E.
Trailing and leading spaces (ASCII 0x20) are not permitted.
NOTE This means that spaces are allowed within the SSID, but not as the first or last
character, and the period “.” (ASCII 0x2E) is also allowed.
VLAN IDs
Each VAP is associated with a VLAN, which is identified by a VLAN ID (VID). A VID
can be any value from 1 to 4094, inclusive. The WAP571/E device supports 33
active VLANs (32 for WLAN plus one management VLAN).
By default, the VID assigned to the configuration utility for the WAP device is 1,
which is also the default untagged VID. If the management VID is the same as the
VID assigned to a VAP, then the WLAN clients associated with this specific VAP
can administer the WAP device. If needed, an access control list (ACL) can be
created to disable administration from WLAN clients.
Configuring VAPs
To configure VAPs:
STEP 1 Select Wireless > Networks in the navigation pane.
STEP 2 Select the Radio interface on which you want to configure VAPs (Radio 1 or Radio
2).
STEP 3 Select the Enabled check box for the VAP you want to configure.
—Or—
If VAP0 is the only VAP configured on the system, and you want to add a VAP, click
Add. Then, select the VAP and click Edit.
STEP 4 Configure the parameters:
• VLAN ID—The VID of the VLAN to associate with the VAP.
CAUTION Be sure to enter a VLAN ID that is properly configured on the network. Network
problems can result if the VAP associates wireless clients with an improperly
configured VLAN.
When a wireless client connects to the WAP device by using this VAP, the WAP
