Client Quality of Service
Class Map
Cisco WAP571/E Administration Guide 127
8
- Match to Port—Matches the destination port in the datagram header
with an IANA port number that you specify. The port range is from 0 to
65535 and includes three different types of ports:
0 to 1023-Well Known Ports
1024 to 49151-Registered Ports
49152 to 65535-Dynamic and/or Private Ports
- Mask—The port mask. The mask determines which bits are used and
which bits are ignored. Only the hexadecimal digit (0 to 0xFFFF) is
allowed. 1 means the bit matters and 0 means that we should ignore this
bit.
• IPv6 Flow Label—Enter a 20-bit number that is unique to an IPv6 packet. It
is used by end stations to signify QoS handling in routers (range 0 to
1048575).
• IP DSCP—Uses the DSCP value as a match criterion.
- Select from List—Choose the DSCP type from the list.
- Match to Value—Enter a custom DSCP value from 0 to 63.
STEP 5 Click Save. The changes are saved to the Startup Configuration.
NOTE To delete a class map, choose it in the Class Map Name list and click Delete. The
class map cannot be deleted if it is already attached to a policy.
Adding a Class Map
To configure a MAC class map:
STEP 1 Select Client QoS > Class Map.
STEP 2 In the Class Map Name field, enter the name for the new class map. The name can
contain from 1 to 31 alphanumeric and special characters. Spaces are not
allowed.
STEP 3 Choose MAC as the type of class map from the Class Map Type list. The MAC
class map applies to Layer 2 criteria.
STEP 4 In the Match Criteria Configuration area, configure these parameters to match the
packets to a class:
