SNMP
Groups
Cisco WAP571/E Administration Guide 149
10
To add and configure an SNMP view:
STEP 1 Select SNMP > Views in the navigation pane.
STEP 2 Click Add to create a new row in the SNMPv3 Views table.
STEP 3 Check the box in the new row and click Edit:
• View Name—Enter a name that identifies the MIB view. View names can
contain up to 32 alphanumeric characters.
• Type—Choose whether to include or exclude the view subtree or family of
subtrees from the MIB view.
• OID—Enter an OID string for the subtree to include or exclude from the view.
For example, the system subtree is specified by the OID string .3.6.1.2.1.1.
• Mask—Enter an OID mask. The mask is 47 characters in length. The format
of the OID mask is xx.xx.xx (.)... or xx:xx:xx.... (:) and is 16 octets in length. Each
octet is two hexadecimal characters separated by either a period (.) or a
colon (:). Only hex characters are accepted in this field.
For example, OID mask FA.80 is 11111010.10000000.
A family mask is used to define a family of view subtrees. The family mask
indicates which subidentifiers of the associated family OID string are
significant to the family's definition. A family of view subtrees enables
efficient control access to one row in a table.
STEP 4 Click Save. The view is added to the SNMPv3 Views list and your changes are
saved to the Startup Configuration.
NOTE To remove a view, select the view in the list and click Delete.
Groups
SNMPv3 groups allow you to combine users into groups of different authorization
and access privileges. Each group is associated with one of three security levels:
• noAuthNoPriv
