Client Quality of Service
Client QoS Association
Cisco WAP571/E Administration Guide 131
8
Client QoS Association
The QoS Association page provides additional control over certain QoS aspects
of the wireless and Ethernet interface. It also provides control of the amount of
bandwidth an individual client is allowed to send and receive.
In addition to controlling general traffic categories, QoS allows you to configure
per-client conditioning of various microflows through Differentiated Services
(DiffServ). DiffServ policies are a useful tool for establishing general micro-flow
definition and treatment characteristics that can be applied to each wireless client,
both inbound and outbound, when it is authenticated on the network.
To configure QoS association parameters:
STEP 1 Select Client QoS > Client QoS Association.
STEP 2 In the Interface field, choose the radio or Ethernet interface on which you want to
configure the QoS parameters.
STEP 3 Select Enabled for the selected interface.
STEP 4 Configure these parameters for the selected interface:
• Bandwidth Limit Down—Enter the maximum allowed transmission rate
from the WAP device to the client in bits per second (bps). The valid range is
from 0 to 1300 Mbps.
• Bandwidth Limit Up—Enter the maximum allowed transmission rate from
the client to the WAP device in bits per second (bps). The valid range is from
0 to 1300 Mbps.
• DiffServ Policy—Choose a DiffServ policy applied to traffic sent to the
WAP device for the selected interface.
STEP 5 Click Save. The changes are saved to the Startup Configuration.
