Clear-Com Tempest 900 Reference Manual

14 Tempest®900 4-Channel Wireless Intercom System
Front Panel Right
1- 2-Wire Intercom Type Slide Switch A&B/C&D
The two 2-Wire Intercom Type slide switches congure the BaseStaon for the type of intercom that will be connected
to the corresponding 2-Wire connectors on the rear panel of the BaseStaon. Clear-Com, RTS, or BAL (AudioCom) can be
selected. This switch only aects 2-Wire operaon and not 4-Wire operaon. The A&B switch selects the 2-Wire system
type for both the A and the B intercom channels. The C&D switch selects the 2-Wire system type for both the C and the D
intercom channels.
2- Wired Intercom Channel Select (SEL) Buon
The Intercom Channel Select (SEL) buon is used to select one of the four intercom channels so that the intercom mode
-- 2-Wire or 4-Wire -- and audio input and output levels, may be adjusted.
Pressing the CHAN SEL buon puts the BaseStaon into Menu Mode and advances to the Intercom Levels screen.
Pressing the CHAN SEL buon a second me selects channel A, for the opportunity to select 2-Wire or 4-Wire or no wired
connecon, and IN and OUT levels can be adjusted (see 2-Wire/4-Wire Select below.)
Addional presses advance through the intercom channels, and return to Operaonal Mode. The intercom channel selected
is indicated by the two “CHAN” LEDs located to the immediate right of the SEL buon.
Also, in the Aux IN/OUT menu, SEL advances through the channels to adjust the Aux IN and Aux OUT levels.
3- Channel (CHAN) LEDs
In Operaonal Mode, the four Channel (CHAN) LEDs labeled A through D are always illuminated.
Enter Menu Mode, by pressing the Channel Select (SEL) buon ([2] above). In Menu Mode, the Channel LEDs indicate the
channel currently selected for adjustment. Only one channel may be selected at a me.
The Front Panel Right controls 1 – 7, will normally be used together to congure the Tempest
BaseStaon for 2-Wire or 4-Wire operaon.
Select the appropriate 2-Wire switch seng prior to connecng the 2-Wire intercom. Do not
switch between 2-Wire types while connected to a 2-Wire system and powered ON. The
dierent voltages in each system may damage equipment.
