98-175666-A Chapter 1: Introduction 1-9
• I/O connector for Tx Mute and Rx Lock.
• Ground wing nut.
• AC Power connector.
• On/Off power switch (at the front).
1.1.4 Satellite type approvals
For a list of satellite type approvals see the SAILOR XTR Ka product page at
www.cobhamsatcom.com.
1.1.5 Service activation
Before you can start using the SAILOR XTR Ka, you need to activate the system for VSAT
service. Contact your service provider for activation.
1.2 Part numbers and options
1.2.1 Applicable model and part numbers
The following model and part numbers are available for the SAILOR XTR Ka system:
1.2.2 Options
The following options are available for the SAILOR XTR Ka system:
Part number Model number Description
407509C-00540 7509C SAILOR 1000 XTR Ka 4.5W ADU
407509D-00540 7509D SAILOR 1000 XTR Ka 9.0 ADU
407506A-00540 7506A SAILOR 600 XTR Ka 4.5W ADU
407506D-00540 7506D SAILOR 600 XTR Ka 9.0W ADU
407516A-00500 7516A SAILOR XTR BDU
407023A-00500 7023A SAILOR Global Xpress Modem Unit GMU
Table 1-2: Model and part numbers for the SAILOR XTR Ka system
Part number Description
407090A-950 Antenna cable 50 m N-Conn (not mounted), male/male
407090A-925 Pigtail Cable 1.25 m, N-Conn, female/male
407090-001 SAILOR 1m SMART Heater, operation down to -55 C
(for 100 cm)
Table 1-3: Model and part numbers for options of the SAILOR XTR Ka system
