Keypad and menus of the BDU
98-175666-A Chapter 4: Setup of the antenna 4-39
MASK 1 Current netmask for LAN 1.
PORT 2 IP Current IP address for LAN 2.
MASK 2 Current netmask for LAN 2.
PORT 3 IP (LAN 3) Current IP address of the SAILOR 1000 XTR Ka 4.5W web
interface (default: 192.168.0.1).
MASK 3 (LAN 3) Current netmask of the SAILOR 1000 XTR Ka 4.5W web
interface (default: 255.255.255.0).
PORT 4 IP Current IP address for LAN 4.
MASK 4 Current netmask for LAN 4.
DEFAULT GATEWAY Current default gateway.
PORT 5 IP Current IP address for LAN 5.
MASK 5 Current netmask for LAN 5.
DEFAULT GATEWAY Current default gateway.
SATELLITE Description
POSITION Position of the current satellite.
RX POLARISATION
Right Hand Circular, Left Hand Circular, auto-selected by the
VSAT modem
TX POLARISATION X-polarization or Co-polarization, auto-selected by VSAT modem
RX FREQUENCY Ka band receiving frequency of the active satellite, auto-selected
by VSAT modem.
LNB LO Auto selected by VSAT modem.
BUC LO
BUC Local Oscillator, auto-selected by VSAT modem
Table 4-18: SATELLITE menu of the BDU
EVENT Description
<EVENT> In this menu all active events are listed. Use
and to go through the
active events.
If a new event occurs or there is a change in the event list while you are in the
EVENTS menu, a * is shown in the upper left corner of the display, next to the
menu name. Press OK to update the EVENTS list, the * will be removed.
A > means the event text is longer than the display can show. Press to > to see
the remaining text.
Table 4-19: EVENTS menu of the BDU
NETWORK Description
Table 4-17: NETWORK menu of the BDU (Continued)
