98-175666-A Chapter 4: Setup of the antenna 4-20
Statistics report
This report contains historical information from the SAILOR XTR Ka of up to 1 month. It is
sent as a zipped attachment to an e-mail. The file format is a comma separated value file
(csv). The report can then be processed in spreadsheet applications, e.g. Microsoft Excel.
To set up sending a statistics report, do as follows:
1. Configure e-mail first, see E-mail setup (secure e-mail) on page 4-17.
2. Go to Settings > Reporting.
3. In the section Statistics report enter the following:
•Email sender.
•Email recipients (comma separated).
•Send interval: Select Daily (2-minute samples), Weekly (hourly samples) or
Monthly (hourly samples).
4. Click Apply.
The following parameters are recorded in the statistics report:
Parameter recorded Description
Host name Host name, entered in the web interface
on the page Settings > Network.
BDU SN BDU serial number
ADU SN ADU serial number
SW ver. Software version
System type SAILOR 1000 XTR Ka 4.5W (example)
Table 4-10: Statistics report, header record
Parameter recorded Description
UTC. (s)
UTC (YYYY-MM-DD hh:mm)
UTC in seconds and date format for the data set.
RSSI.Av
RSSI.Max
RSSI.Min
Received signal strength (average, maximum and
minimum value) for the sampling interval.
POS.Lat (degree)
POS.Long (degree)
POS.Valid
Latitude value of position.
Longitude value of position.
Fix = valid position, No Fix = invalid position.
Heading.Samp (degree)
Heading.Max (degree)
Heading.Min (degree)
Heading.Range (+/-degree)
Ship’s heading (sample, maximum and minimum
value, range) for the sampling interval. See Figure 4-
18: Statistics — how to read data for a range.
Table 4-11: Parameters in a statistics report
