Introduction to the web interface
98-175666-A Chapter 4: Setup of the antenna 4-4
Tracking RF frequency Antenna tracking frequency
MODEM
Model VSAT modem model used with the currently active VSAT profile
RX locked status Shows whether the modem is in lock with the hub
Status Status information received from modem. Not available for all
models.
Signal level RSSI information from the modem
Reference Shows the BUC and LNB reference source
RX IF frequency Shows the L-band RX frequency selected by the modem
TX IF frequency Shows the L-band TX frequency used by the modem
TX allowed On or Off. Indicates if the modem supplies BUC reference signal
on its TX connector and if the modem indicates Rx locked and Tx
ON (e.g. OpenAMIP message L (L 1 1).
POINTING
GNSS position latitude Current position of the vessel, reported by built-in GNSS module
or external GPS source.
GNSS position
longitude
Current position of the vessel, reported by built-in GNSS module
or external GPS source.
GNSS position altitude Current position of the vessel, reported by built-in GNSS module
or external GPS source.
Vessel heading Ship's heading in degrees with reference to North, provided by
ship's gyro.
Azimuth (Geographic) Current antenna pointing for geographic azimuth
Elevation (Geographic) Current antenna pointing for geographic elevation
Azimuth (Relative) Current antenna pointing for relative azimuth
Elevation (Relative) Current antenna pointing for relative elevation
Polarization skew LNB skew angle to the current satellite
SYSTEM INFO
BDU part name BDU model
BDU serial number BDU serial number, used for service cases
Antenna part name ADU model
Antenna serial number ADU serial number, used for service cases
Engineering version Active software version
Parameter Description
Table 4-1: Sections and parameters on the Dashboard (Continued)
