INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
90 Envoy™ Transceiver Getting Started Guide
Connecting a desk console
The desk console may be attached directly to the RFU using cable
08-07205-xxx, or remotely via Ethernet.
Connecting an automatic tuner to the RF unit and antenna
(optional)
NOTE: You may need to install a tuner to improve the
efficiency of the antenna in your fixed station
(see the reference material on the enclosed CD).
NOTE: The tuner used in most applications has
connectors at the end of the cables attached to the
tuner, as described below. However, you may
have a tuner that has sockets on the connector
panel of the tuner.
To connect the tuner to the RF unit:
1 Connect the plug at the end of the coaxial cable from the
tuner to the socket at the end of the cable lead from the RF
unit, then secure the locking ring tightly into position.
1 Connect the plug at the end of the control cable from the
tuner to the socket at the end of the cable lead from the RF
unit, then secure the locking ring tightly into position.
1 Connect the antenna to the antenna connector on the tuner,
then secure it tightly into position.
Connecting the transceiver supply
To connect the transceiver to the transceiver supply:
1 Connect the DC output from the transceiver supply to the
plug at the end of the 12 V cable lead from the RF unit.
1 Connect the transceiver supply to the AC mains supply.
