OPERATING THE TRANSCEIVER
THE CHANNEL SCREEN
50 ENVOY™ TRANSCEIVER GETTING STARTED GUIDE
If the transmit and receive frequencies are the same, the frequency
is only shown on the right side of the screen. The Rx/Tx indicator
shows whether the transceiver is receiving (green) or transmitting
(red). The more bars that are shown, the higher the signal strength.
Your transceiver may have the option of selecting high, medium,
or low power. Hi, Med, or Lo is shown respectively to the right of
the signal strength indicator.
While a call is being established, the transceiver shows that calling
activity is in progress by flashing in place of the scan indicator.
Once a call is established, these indicators are replaced with an icon
that represents the type of call being sent or received.
When the transceiver is scanning, the channel screen is replaced by
the scanning screen.
Figure 18: Scanning screen
