INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
Envoy™ Transceiver Getting Started Guide 89
Rack-mounting unit
A rack-mounting unit consists of a 19 inch rack tray. It can be used
to mount your fixed station with either a desk console or the
handset and cradle.
Connecting a fixed Envoy™ station
To connect a fixed station:
1 Do one of the following:
• Connect the lead from the handset and speaker
connector to the 10-way plug on the flying lead from
the RF unit, then secure the locking ring tightly into
position.
• Connect the 6 m flying lead from the optional 2230
Desk Console to the 10-way plug on the flying lead
from the RF unit, then secure the locking ring tightly
into position.
1 Do one of the following:
• Connect the plug of the handset cable to the socket
on the handset and speaker connector, then secure
the locking ring tightly into position.
• Connect the optional 2230 Desk Console and the
RFU directly using cable 08-07205-xxx, then secure
the locking ring tightly into position.
1 If you are using the handset and speaker connector and
cable, connect the plug at the end of the speaker cable to the
socket on the handset and speaker connector, then secure
the cable by pushing it into the slot on the side of the
connector.
1 Connect the plug at the end of the cable to the socket at the
end of the cable lead from the RF unit, then secure the
locking ring tightly into position.
1 Connect the plug at the opposite end of the cable to the
socket located at the base of the antenna, then secure the
locking ring tightly into position.
