INSTALLING THE TRANSCEIVER
OVERVIEW OF MOBILE STATIONS
84 Envoy™ Transceiver Getting Started Guide
1 Place the RF unit into the cradle and push it under the tabs
at the rear of the cradle, then hold the clamp against the front
of the RF unit.
1 Rotate the key clockwise, then push the key toward the base
of the cradle to lock the RF unit into position.
Connecting a mobile Envoy™ station
To connect a mobile station:
1 Connect the lead from the handset and speaker connector to
the 10-way plug on the cable lead from the RF unit, then
secure the locking ring tightly into position.
1 Connect the plug of the handset cable to the socket on the
handset and speaker connector, then secure the locking ring
tightly into position.
1 Connect the plug at the end of the speaker cable to the
socket on the handset and speaker connector, then secure the
cable by pushing it into the slot on the side of the connector.
1 Connect the plug at the end of the cable to the socket at the
end of the cable lead from the RF unit, then secure the
locking ring tightly into position.
1 Connect the plug at the opposite end of the cable to the
socket located at the base of the antenna, then secure the
locking ring tightly into position.
