ComAp InteliATS PWR User Manual

InteliATS
NT
PWR, SW version 2.5, ©ComAp – May 2015 56
IA-NT- PWR-2.5-Reference Guide.pdf
Nominal Freq [Hz]
Nominal generator frequency (usually 50 or 60 Hz )
Step: 1 Hz
Range: 45 – 65 Hz
GenerProtect [ENABLED/DISABLED]
Setpoint enable or disable evaluating of generator voltage and frequency values.
ENABLED: Values are used for evaluating of state of source and for protections.
DISABLED: Values are not used for evaluating of state of source and for protections. If terminal for
measurement are connected to controller, values are just shown on measuring screen. More info can
be found in chapter Source evaluation or in description of binary input GenReadyToLoad.
NOTE:
When binary input GenReadyToLoad isn’t configured, the setpoint GenerProtect is adjust to value
ENABLED and this value can’t be changed.
MainsProtect [ENABLED/DISABLED]
Setpoint enable or disable evaluating of mains voltage and frequency values.
ENABLED: Values are used for evaluating of state of source and for protections.
DISABLED: Values are not used for evaluating of state of source and for protections. If terminal for
measurement are connected to controller, values are just shown on measuring screen. More info can
be found in chapter Source evaluation or in description of binary input MainsReadyToLoad.
NOTE:
When binary input MainsHealthy isn’t configured, the setpoint MainsProtect is adjust to value
ENABLED and this value can’t be changed.
ActivityAtOFF [ENABLE/DISABLE]
ENABLE: Controller at OFF mode stays at standard behavior of OFF mode.
DISABLE: Controller at OFF mode opens all binary outputs (MCB Close/Open and Gen
Start/Stop outputs are depend on MCB Logic and GenStartLogic setpoints) and there
is Fault reset active all the time.
ControllerMode [OFF, MAN, AUT,TEST]
Equivalent to Controller mode changes by MODE or MODE buttons.
NOTE:
Controller Mode change can be separately password protected.
GenStart Logic [CLOSE-ON/CLOSE-OFF]
The set point influences the behavior of the output Gen Start/Stop.
CLOSE-ON: Gen-set should start when the output Gen Start/Stop is closed.
CLOSE-OFF: Gen-set should start when the output Gen Start/Stop is opened.
Batt Undervolt [V]
Warning threshold for low battery voltage.
Step: 0.1 V
Range: 8V – 40 (Battery >Volts)
Batt Overvolt [V]
Warning threshold for hi battery voltage.
Step: 0.1 V
Range: 8 V – 40 (Battery <Volts)
Batt Volt Del [s]
Delay for low battery voltage alarm.
