InteliLite4 AMF20 Global Guide
221
Zero Power Mode
Setpoint group Basic settings Related FW 1.3.0
Range [units] Disabled / 1 .. 360 [min]
Default value Disabled Alternative config NO
Step 1 min
Comm object 8548 Related applications AMF,MRS
Config level Advanced
Setpoint visibility Conditioned by the setpoint Default Application Select (page 217)
Description
The controller is switched to Zero Power Mode when there is no user interaction with the controller for the
preset time period. For the controller wake up press button Start or activate Binary Input 1. The controller
will not switch to Zero Power Mode if generator is running. In Zero Power Mode binary outputs go to high
impedance.
Note: Power consumption of controller in Zero Power Mode is 0mA. Controller is internally
disconnected from power supply.
Note: While there is USB power present (USB cable plagued) the controller is able to turn off when
there is no user interaction but wake up is not possible. USB power has to be cut off (USB cable un-
plugged).
6 back to List of setpoints
Run Hours Source
Setpoint group Basic settings Related FW 1.3.0
Range [units] AUTO / ECU / INTERNAL [-]
Default value AUTO Alternative config NO
Step [-]
Comm object 13345 Related applications AMF,MRS
Config level Advanced
Setpoint visibility Always
Description
This setpoint selects source of running hours.
AUTO If there is some ECU which send valid running hours, then this value is used.
Otherwise value from internal counter is used.
ECU Running hours are taken from ECU if ECU send valid data. It is not possible to set
and reset this value in statistics.
INTERNAL Running hours are taken from internal counter. It is possible to set and reset this
value in statistics.
Note: It is not necessary to restart controller when this setpoint is changed. Change of this setpoint is
applied immediately.
6 back to List of setpoints
