InteliLite Global Guide
258
Subgroup: AMF Voltage Conditions
Setpoint group AMF settings Related FW 1.9.0
Range [units] Mains Undervoltage (page 258) .. 150 [%]
Default value 110 % Alternative config NO
Step 1 % of Nominal Voltage Ph-Ph (page 195)
Comm object 8305 Related applications AMF
Config level Standard
Setpoint visibility Conditioned by the setpoint Operation Mode (page 199)
Description
Threshold for mains overvoltage. All three phases are checked. Maximum out of three is used.
Mains Overvoltage
6 back to List of setpoints
Setpoint group AMF settings Related FW 1.9.0
Range [units] 50 .. Mains Overvoltage (page 258) [%]
Default value 60 % Alternative config YES
Step 1 % of Nominal Voltage Ph-Ph (page 195)
Comm object 8307 Related applications AMF
Config level Standard
Setpoint visibility Conditioned by the setpoint Operation Mode (page 199)
Description
Threshold for mains undervoltage. All three phases are checked. Minimum voltage out of three phases is
used.
Mains Undervoltage
6 back to List of setpoints
Setpoint group AMF settings Related FW 1.9.0
Range [units] 0,0 .. 600,0 [s]
Default value 2,0 s Alternative config YES
Step 0,1 s
Comm object 8306 Related applications AMF
Config level Standard
Setpoint visibility Conditioned by the setpoint Operation Mode (page 199)
Description
Delay for Mains Undervoltage (page 258) and Mains Overvoltage (page 258) protection.
Mains < > Voltage Delay
6 back to List of setpoints
