ComAp InteliLite AMF25 - Page 195

InteliLite Global Guide
195
Setpoint group Basic settings Related FW 1.9.0
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 8277 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 193).
Description
Nominal voltage (phase to neutral).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-N 1
(page 356), Nominal Voltage Ph-N 2 (page 360) and Nominal Voltage Ph-N 3 (page 364).
Nominal Voltage Ph-N
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 11657 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 193).
Description
Nominal system voltage (phase to phase).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-Ph 1
(page 356), Nominal Voltage Ph-Ph 2 (page 360) and Nominal Voltage Ph-Ph 3 (page 364).
Nominal Voltage Ph-Ph
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 0,1 .. 500,0 [V/V]
Default value 1,0 V/V Alternative config NO
Step 0,1 V/V
Comm object 9579 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
Generator voltage potential transformers ratio. If no PTs are used, adjust the setpoint to 1.
PT Ratio
6 back to List of setpoints
