ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
341
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config Yes
Step 1 kW
Comm object 12048 Related applications AMF, MRS,
Config level Standard
Setpoint visibility Always
Description
Nominal power of the gen-set. Generator Overload BOC (page 227) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 177) is adjusted to Monophase or
Splitphase or 3Ph3Wire or High Leg D or 3Ph4Wire or when Autodetect detects connection type as
3Ph3Wire or High Leg D or 3Ph4Wire.
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 499) is active.
Nominal Power 3
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config Yes
Step 1 kW
Comm object 15773 Related applications AMF, MRS,
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 177)
Description
Nominal power of the gen-set for detected split-phase or mono phase connection. Generator Overload BOC
(page 227) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 177) is adjusted to Autodetect and
Autodetect detects connection type as Monophase or Splitphase.
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 499) is active.
Nominal Power Split Phase 3
6 back to List of setpoints

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
